81 GHz to 86 GHz, 1 W E-Band Power Amplifier with Power Detector Data Sheet ADMV7810 FEATURES GENERAL DESCRIPTION Gain: 20 dB typical
The ADMV7810 is an integrated E-band gallium arsenide (GaAs),
Output power for 1 dB compression: 28 dBm typical
pseudomorphic, high electron mobility transfer (pHEMT), mono-
Saturated output power: 29 dBm typical
lithic microwave integrated circuit (MMIC), medium power
Output third-order intercept: 33 dBm typical
amplifier with a temperature compensated on-chip power detector
Input return loss: 12 dB typical
that operates from 81 GHz to 86 GHz. The ADMV7810 provides
Output return loss: 20 dB typical
20 dB of gain, 28 dBm of output power at 1 dB compression, and
DC supply: 4 V at 800 mA
29 dBm of saturated output power at 18% power added efficiency
No external matching required
from a 4 V power supply. The ADMV7810 exhibits excellent
Die size: 2.999 mm × 3.799 mm × 0.05 mm
linearity and is optimized for E-band communications and
APPLICATIONS
high capacity wireless backhaul radio systems. The amplifier configuration and high gain make the device an excellent
E-band communication systems
candidate for last stage signal amplification before the antenna.
High capacity wireless backhaul radio systems
All data is taken with the chip in a 50 Ω test fixture connected via
Test and measurement
a 3 mil wide × 0.5 mil thick × 7 mil long ribbon on each port. The ADMV7810 is available in a 40-pad bare die (CHIP) and operates over the −55°C to +85°C temperature range.
FUNCTIONAL BLOCK DIAGRAM 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 A 2A A G 4A GG1 DD1A DD2A A G V V VG V DD4 VG V GG3 DD3A V V ADMV7810 20 RFOUT 21 22 3 RFIN 2 1 3B G B B VG B B 4B G GG1 DD1 GG2 DD3B DD4B ET EF V V V DD2 V V VG V VD VR
1 -00
40 39 38 37 36 35 34 33 32 31 30 29 28 27 26 25 24 23
409 16 Figure 1.
